PAX D135 Card Reader

The Pax D135 is a compact, mobile smart card reader designed for modern businesses on the go. Whether you're accepting payments in-store or out in the field, the D135 connects seamlessly to your Android or iOS device via Bluetooth, transforming your phone or tablet into a powerful payment terminal.

Features

• Supports Android devices

• Chip + Contactless + Swipe

• Bluetooth BT4.2, supports LE mode, metal PIN charging & communication

• 400mAh battery

Specifications

• Brand: PAX

• Product Type: Monitor mPOS

• Length: 2.64"

• Width: 0.51"

• Height: 2.64"

• Weight: 0.14 lbs

• Operating System: Monitor

• Processor: Cortex M3

• Memory: Built-in 1MB FLASH + 128KB SRAM | External 4MB SPI Nor Flash for Fonts, Config Files

• Card Readers: Chip & PIN | NFC Contactless | Magnetic Stripe (optional)

• Comms Configurations: BT4.2, Supports BLE | 1xUSB Type C | Optional Pogo PIN

• Battery: 250mAh | Optional 400mAh

• Keys/Buttons, 1 Button: Power On / Power Off / Sleep / Pair to Bluetooth COTS

• Indicators: 4 RF Indicators, 1 Power Indicators (Green & Red)

• Cable: 1 x USB Cable

• Audio: 1 Buzzer

• Ports: 1 Type C USB OTG | POGO PIN (optional)

• Operating Temperature: -10°C ~ 50°C (14°F ~ 122°F)

• Storage Temperature: -20°C ~ 70°C (-4°F ~ 158°F)

• Relative Humidity, Non-Condensing: 10%-93%

Certifications

• PCI PTS 5.x SRED

• EMV L1 & L2

• EMV CL L1

• MasterCard Contactless L2

• Visa payWave L2

• DPAS L2

• QUICS L2

• AMEX L2

• InteacFlash L2

• TQM, UL, FCC, IC, RoHs
